The machine frame is manufactured by using steel which makes it suitable to withstand high vibrations generated due to the motor rotation and the cutting operation. It is also provided with a clutch system for the safe and efficient working.
Bar Cutting Specifications
Key Feature
Input Voltage (Phase/Current/ Freq) : THREE PHASE 50-60 Hz
Diameter (TMT Threaded Steel) : ⌀4mm-⌀28mm
Diameter (Round Bar) : ⌀6mm-⌀32mm
Cutting Frequency : 32 Times/ Min
Working Type : Manual Push Type
Motor Power (Voltage) : 380V/415V
Motor RPM : 2800 RPM 3.0kW
Sizes and Dimension
Dimensions : 1120X330X620MM
Weight : 380 KGS
